The order uses outdoor P6.67 module with size 320x320mm; the lamp beads use Nation Star SMD2727, high refresh rate driver IC to ensure the brightness and refresh rate of the LED display.
The display size after installation is 2.56×1.92m
High quality P6.67 320×320 dual service outdoor LED module.
The brightness reaches 6000cd/㎡, the module size is 320x320mm, the refresh rate reaches 1920Hz and can be combined with a high quality cabinet to achieve IP65 protection.
Use the new Novastar receiving card MRV328. The MRV328 is a new receiving card developed by NovaStar.
The power supply uses high quality South creative’s NDA200HS5
Input: 200-240VAC
Output: 5V 60A
4 high quality cooling fans installed in each cabinet
Open holes at the sides of the cabinet to allow network cables and power cables connected between the cabinets to pass through here. In this way, the outside of the cabinet will be very neat and no extra wires will be seen.
The video of P6.67 Outdoor Double Maintenance Aluminum Box To Cameroun
